คุณสมบัติ | รายละเอียด |
|---|---|
| Number of Cores | 3 |
| Cross Sectional Area | 0.25 mm² |
| Sheath Colour | Grey |
| Sheath Material | PUR |
| Length | 2m |
| Connector 1 | M8 |
| Connector 1 Gender | Female |
| Connector 1 Orientation | Right Angle |
| Connector 1 Number of Contacts | 3 |
| Connector 2 Housing Gender | Male |
| Connector 2 Orientation | Straight |
| Connector 2 Number of Contacts | 3 |
| Connector 2 | M12 |
| Connector 2 Gender | Male |
| Shielded/Unshielded | Unshielded |
| Current Rating | 4 A |
| Voltage Rating | 60 V ac/dc |
| IP Rating | IP65, IP67 |
| Connector 1 Housing Gender | Female |
| Operating Temperature Range | -25 → +85 °C |
| Minimum Bend Radius | 10 x 4.5 mm |
| Cable Shape | Multicore |
| Insulation Material | PVC |
| Oil Resistant | Yes |
| Standards Met | CSA, UL |
| Maximum Operating Temperature | +85°C |
| American Wire Gauge | 24 AWG |
| Outer Diameter | 4.5mm |
| Minimum Operating Temperature | -25°C |
| Fire Behaviour | Flame Retardant |
88673 RKMW 3-338/3 M
XS3F-M8PVC4S5M-EU
T4062123003-005
T4151420008-003
