คุณสมบัติ | รายละเอียด |
|---|---|
| Cross Sectional Area | 0.25 mm² |
| Number of Cores | 4 |
| Length | 5m |
| Sheath Colour | Grey |
| Sheath Material | PUR |
| Connector 1 Gender | Male |
| Connector 1 | M8 |
| Connector 1 Orientation | Right Angle |
| Connector 1 Number of Contacts | 4 |
| Connector 2 | Unterminated |
| Shielded/Unshielded | Unshielded |
| Voltage Rating | 30 V ac/dc |
| Current Rating | 4 A |
| IP Rating | IP65, IP67 |
| Minimum Operating Temperature | -25°C |
| Maximum Operating Temperature | +85°C |
| Standards Met | CSA, UL |
| Oil Resistant | Yes |
| Cable Shape | Multicore |
| Outer Diameter | 4.8mm |
| American Wire Gauge | 24 AWG |
| Minimum Bend Radius | 10 x 4.8 mm |
| Fire Behaviour | Flame Retardant |
| Operating Temperature Range | -25 - +85 °C |
| Connector 1 Housing Gender | Male |
| Insulation Material | PVC |
21348100481050
21349300477010
11824 RST 4-RKT 4-225/1,5 M
79-3386-42-04
