คุณสมบัติ | รายละเอียด |
|---|---|
| Cross Sectional Area | 0.25 mm² |
| Number of Cores | 4 |
| Length | 5m |
| Sheath Material | PUR |
| Sheath Colour | Grey |
| Connector 1 | M8 |
| Connector 1 Number of Contacts | 4 |
| Connector 1 Gender | Female |
| Connector 1 Orientation | Straight |
| Connector 2 | Unterminated |
| Shielded/Unshielded | Unshielded |
| Voltage Rating | 30 V ac/dc |
| Current Rating | 4 A |
| IP Rating | IP65, IP66K, IP67, IP68 |
| Minimum Bend Radius | 10 x 4.8 mm, 5 x 4.8 mm |
| Insulation Material | PVC |
| Conductor Material | Copper |
| Oil Resistant | Yes |
| Conductor Resistance | 60 Ω/km |
| American Wire Gauge | 24 AWG |
| Maximum Operating Temperature | +85°C |
| Standards Met | CSA, cSAus, EN 60529, UL |
| Outer Diameter | 4.8mm |
| Core Strands | 14/0.15 mm |
| Connector 1 Housing Gender | Female |
| Number of Strands | 14 |
| Cable Shape | Multicore |
| Operating Temperature Range | -25 → +85 °C |
| Minimum Operating Temperature | -25°C |
| Fire Behaviour | Flame Retardant |
| Size of Strands | 0.15 mm |
