คุณสมบัติ | รายละเอียด |
|---|---|
| Number of Cores | 5 |
| Cross Sectional Area | 0.34 mm² |
| Length | 2m |
| Sheath Material | PUR |
| Sheath Colour | Grey |
| Connector 1 Orientation | Right Angle |
| Connector 1 Number of Contacts | 5 |
| Connector 1 Gender | Female |
| Connector 1 | M12 |
| Connector 2 | M12 |
| Connector 2 Housing Gender | Male |
| Connector 2 Orientation | Straight |
| Connector 2 Number of Contacts | 5 |
| Connector 2 Gender | Male |
| Shielded/Unshielded | Unshielded |
| Current Rating | 4 A |
| Voltage Rating | 125 V ac/dc |
| IP Rating | IP65, IP67 |
| Oil Resistant | Yes |
| Cable Shape | Multicore |
| Connector 1 Housing Gender | Female |
| Operating Temperature Range | -25 → +85 °C |
| Outer Diameter | 5.2mm |
| American Wire Gauge | 22 AWG |
| Minimum Bend Radius | 10 x 5.2 mm |
| Insulation Material | PVC |
| Fire Behaviour | Flame Retardant |
| Minimum Operating Temperature | -25°C |
| Maximum Operating Temperature | +85°C |
| Standards Met | CSA, UL |
MSXS08ML-SXSML-SX020
7000-08061-6311000
3-1437720-8
