คุณสมบัติ | รายละเอียด |
|---|---|
| Coil Voltage | 24V dc |
| Contact Configuration | 4PDT |
| Mounting Type | Plug In |
| Switching Current | 10A |
| Number of Poles | 4 |
| Latching | No |
| Terminal Type | Plug In |
| Maximum Switching Voltage AC | 250V ac |
| Maximum Switching Voltage DC | 30V dc |
| Length | 41.5mm |
| Coil Power | 300W |
| Depth | 28mm |
| Standards Met | CE, CQC, CULus, RoHS Compliant |
| Contact Material | Silver Alloy |
| Life | 100000 (Electrical) cycles, 10000000 (Mechanical) cycles |
| Minimum Operating Temperature | -25°C |
| Height | 36.5mm |
| Maximum Operating Temperature | +55°C |
| Isolation Coil To Contact | 2kV ac |
| Maximum Switching Power AC | 2.5VA |
| Maximum Switching Power DC | 1.5 W |
| Application | General Purpose |
MY2N1-D2 DC24(S)
MY4ZN DC24(S)
HF140FF/005-2HTF
202180240000
V23148A1105A101
