คุณสมบัติ / Specifications
| คุณสมบัติ | รายละเอียด |
|---|---|
| Minimum Input Voltage | 30V dc |
| Maximum Input Voltage | 56V dc |
| Output Voltage | 48 V dc |
| Minimum Output Voltage | 48V dc |
| Maximum Output Voltage | 48V dc |
| Output Current | 40 A |
| Number of Outputs | 1 |
| Width | 125mm |
| Weight | 750g |
| Minimum Temperature | -40°C |
| Special Features | Consistent Redundancy Up To The Load, Flexible, Rugged Design |
| Standards Met | CSA, CUL, CULus, DNV GL, EAC, PRS, UL |
| Mounting Type | DIN Rail |
| Power Signal Conversion Type | DC-DC |
| Series | QUINT4-DIODE/48DC/2X20/1X40 |
| MTBF | 40000000h |
| Hazardous Area Certification | ATEX, Ex Approval, IECEx |
| Maximum Input Current | 60A |
| Protection Features | Shock Current Protection |
| Maximum Temperature | +70°C |
