คุณสมบัติ / Specifications
| คุณสมบัติ | รายละเอียด |
|---|---|
| Minimum Input Voltage | 100 V ac, 110 V dc |
| Input Voltage | 230V ac |
| Maximum Input Voltage | 240 V ac, 250 V dc |
| Output Voltage | 15 V dc |
| Minimum Output Voltage | 12V dc |
| Maximum Output Voltage | 15V dc |
| Output Current | 15 A |
| Power Rating | 180W |
| Number of Outputs | 1 |
| Electrical Phase | 1 |
| Type | Switch Mode |
| Height | 130mm |
| Dimensions | 50 x 125 x 130mm |
| Width | 50mm |
| Allowed Circuit Configurations | Parallel, Series |
| Minimum Temperature | -25°C |
| Input Frequency Range | 50 → 60Hz |
| Protection Features | Transient Surge Protection |
| Ripple And Noise | 50mV Pk-Pk |
| Depth | 125mm |
| Maximum Input Current | 2.4 A @ 100 V ac |
| Weight | 1.3kg |
| Maximum Temperature | +70°C |
| Series | QUINT4 |
| Mounting Type | DIN Rail |
| Input Electrical Phase | 1 |
| Application | Industrial |
