คุณสมบัติ / Specifications
| คุณสมบัติ | รายละเอียด |
|---|---|
| Input Voltage | 230V ac |
| Minimum Input Voltage | 85V ac |
| Maximum Input Voltage | 240V ac |
| Output Voltage | 24 V dc |
| Minimum Output Voltage | 24V dc |
| Maximum Output Voltage | 29.5V dc |
| Output Current | 10 A |
| Power Rating | 240W |
| Number of Outputs | 1 |
| Height | 130mm |
| Width | 50mm |
| Input Frequency Range | 50 → 60Hz |
| Ripple And Noise | <80mV Pk-Pk |
| Minimum Temperature | -25°C |
| Hazardous Area Certification | Ex Approval |
| Special Features | Easy System Extension, High Degree of Immunity, Preventive Function Monitoring Indicates Critical Operating States Before Errors Occur, SFB Technology Trips Standard Circuit Breakers Selectively |
| Input Electrical Phase | Single Phase |
| Mounting Type | DIN Rail |
| Depth | 125mm |
| Power Signal Conversion Type | AC/DC-DC |
| Series | QUINT4-PS/1AC/24DC/10 |
| MTBF | >1250000h |
| Standards Met | CSA, CUL, CULus, DNV GL, EAC, PRS, UL |
| Maximum Temperature | +70°C |
| Protection Features | Transient Surge Protection |
| Maximum Input Current | 3.4A |
| Weight | 900g |
