คุณสมบัติ / Specifications
| คุณสมบัติ | รายละเอียด |
|---|---|
| Minimum Input Voltage | 85V ac |
| Maximum Input Voltage | 264V ac |
| Output Voltage | 15 V dc |
| Minimum Output Voltage | 15V dc |
| Maximum Output Voltage | 15V dc |
| Output Current | 6.67 A |
| Power Rating | 100W |
| Number of Outputs | 1 |
| Width | 55mm |
| Line Regulation | <0.1% |
| Minimum Temperature | -25°C |
| Allowed Circuit Configurations | Parallel, Series |
| Output Voltage Adjustment Range | ±1% |
| Mounting Type | DIN Rail |
| Power Signal Conversion Type | AC-DC |
| Weight | 340g |
| Maximum Temperature | +70°C |
| Input Frequency Range | 45 → 65Hz |
| Ripple And Noise | <75mV Pk-Pk |
| Special Features | Maximum Energy Efficiency Thanks to Optimized Efficiency Over the Entire Operating Range of the Power Supply Unit and Low no Load Losses |
| Protection Features | Transient Surge Protection |
| MTBF | >500000h |
| Series | UNO |
| Standards Met | CB Scheme, DIN VDE 0100-410, EN 50178/VDE 0160 (PELV), EN 60204-1, EN 60715, EN 60950-1 (SELV) and EN 60204 (PELV), EN 60950-1/VDE 0805 (SELV), EN 61000-3-2, EN 61000-4-11, EN 61000-6-2:2005, EN 61558-2-16, UL Listed UL 508, UL/C-UL Recognized UL 60950 |
| Application | Industrial, Residential |
| Input Electrical Phase | Single Phase |
