คุณสมบัติ / Specifications
| คุณสมบัติ | รายละเอียด |
|---|---|
| Input Type | Current, Voltage |
| Output Type | Current, Transistor |
| Signal Conditioner Type | Isolation |
| Output Range | 5 kHz |
| Supply Voltage | 9.6 → 30 V dc |
| Mounting Type | DIN Rail |
| Sensor Compatibility | NAMUR Sensor |
| Minimum Operating Temperature | -40°C |
| Maximum Operating Temperature | +70°C |
| Number of Channels | 1 |
| Termination | Screw |
| Standards Met | ATEX, CE, EN 60715, EN 60947-5-6, EX-Zone 2, IEC 610101-1, UL, UL 508, USA |
| Module Type | Amplifier |
| Special Features | Inputs and Outputs are Configurable via DIP Switches, Screw or Push-In Connection Available |
| Series | MINI MCR |
| Operating Temperature Range | -40 → +70 °C |
