คุณสมบัติ / Specifications
| คุณสมบัติ | รายละเอียด |
|---|---|
| Minimum Input Voltage | 320V ac |
| Maximum Input Voltage | 575V ac |
| Output Voltage | 24 V dc |
| Minimum Output Voltage | 18V dc |
| Maximum Output Voltage | 29.5V dc |
| Output Current | 20 A |
| Electrical Phase | 3 |
| Type | Switch Mode |
| Height | 130mm |
| Dimensions | 125 x 69 x 130mm |
| Width | 69mm |
| CAD Drawing | 3D CAD Model |
| Ripple And Noise | 40mV Pk-Pk |
| Input Electrical Phase | Three Phase |
| MTBF | 500000h |
| Series | QUINT |
| Maximum Temperature | +70°C |
| Minimum Temperature | -25°C |
| Weight | 1.5kg |
| Depth | 130mm |
