คุณสมบัติ | รายละเอียด |
|---|---|
| Series | SAC-4P-M |
| Cross Sectional Area | 0.25 mm² |
| Number of Cores | 4 |
| Sheath Material | PUR |
| Sheath Colour | Black/Grey |
| Length | 300mm |
| Connector 1 Orientation | Straight |
| Connector 1 Gender | Male |
| Connector 1 Number of Contacts | 4 |
| Connector 1 | M8 |
| Connector 2 | M8 |
| Connector 2 Housing Gender | Female |
| Connector 2 Number of Contacts | 4 |
| Connector 2 Gender | Female |
| Connector 2 Orientation | Straight |
| Coding | A |
| Shielding | Unshielded |
| Voltage Rating | 30 V |
| Current Rating | 4 A |
| IP Rating | IP65, IP67, IP68 |
| Connector 1 Housing Gender | Male |
| Operating Temperature Range | -40 - +80 °C |
| Maximum Operating Temperature | +80°C |
| Conductor Material | Bare Cu litz wires |
| Minimum Bend Radius | 22 mm (Fixed), 44 mm (Movable) |
| Fire Behaviour | Flame Retardant |
| Insulation Material | PP |
| American Wire Gauge | 24 AWG |
| Minimum Operating Temperature | -40°C |
| Oil Resistant | Yes |
| Cable Shape | Twisted Pair |
| Standards Met | cULus |
| Outer Diameter | 4.4mm |
