คุณสมบัติ | รายละเอียด |
|---|---|
| Cross Sectional Area | 0.25 mm² |
| Sheath Material | PUR |
| Length | 5m |
| Sheath Colour | Black |
| Connector 1 | M8 |
| Connector 1 Orientation | Straight |
| Connector 1 Number of Contacts | 3 |
| Connector 1 Gender | Female |
| Connector 2 | Unterminated |
| Coding | A |
| Shielded/Unshielded | Unshielded |
| Voltage Rating | 48 V |
| Current Rating | 4 A |
| IP Rating | IP65, IP67, IP68 |
| Oil Resistant | Yes |
| Minimum Operating Temperature | -25°C |
| Insulation Material | PP |
| American Wire Gauge | 24 AWG |
| Connector 1 Housing Gender | Female |
| Conductor Resistance | 78 O/km |
| Outer Diameter | 3.6mm |
| Maximum Operating Temperature | +90°C |
| Fire Behaviour | Halogen Free |
| Standards Met | cUL, cULus, EAC, IEC 61076-2-104, UL |
| Minimum Bend Radius | 18 (Fixed) mm, 36 (Movable) mm |
| Conductor Material | Copper |
| Cable Shape | Twisted Pair |
