คุณสมบัติ | รายละเอียด |
|---|---|
| Series | SAC |
| Number of Cores | 8 |
| Cross Sectional Area | 8x 0.25 mm² |
| Length | 300mm |
| Sheath Colour | Black/Grey |
| Sheath Material | PUR |
| Connector 1 Number of Contacts | 8 |
| Connector 1 Gender | Male |
| Connector 1 | M12 |
| Connector 1 Orientation | Straight |
| Connector 2 | M12 |
| Connector 2 Housing Gender | Female |
| Connector 2 Number of Contacts | 8 |
| Connector 2 Orientation | Straight |
| Connector 2 Gender | Female |
| Coding | A |
| Current Rating | 2 A |
| Voltage Rating | 30 V |
| IP Rating | IP65, IP67, IP68 |
| Fire Behaviour | Halogen Free, Self-extinguishing |
| Minimum Operating Temperature | -40°C |
| Connector 1 Housing Gender | Male |
| Standards Met | IEC 61076-2-101 |
| Oil Resistant | Yes |
| Operating Temperature Range | -40 → +80 °C |
| Insulation Material | PP |
| Outer Diameter | 5.9 mm ±0.15mm |
| American Wire Gauge | 24 AWG |
| Conductor Resistance | 5 mO |
| Maximum Operating Temperature | +80°C |
| Minimum Bend Radius | 10 x D (Flexible), 8 x D (Fixed) |
| Conductor Material | Bare Cu litz wires |
