คุณสมบัติ | รายละเอียด |
---|---|
Series | SAC |
Number of Cores | 12 |
Sheath Colour | Black |
Sheath Material | PUR |
Length | 1.5m |
Connector 1 Orientation | Straight |
Connector 1 | M12 |
Connector 1 Gender | Female |
Connector 1 Number of Contacts | 12 |
Connector 2 | Unterminated |
Coding | A |
Shielded/Unshielded | Unshielded |
Voltage Rating | 30 V |
Current Rating | 1.5 A |
IP Rating | IP65, IP67, IP68 |
Insulation Material | PP |
Conductor Resistance | 142 Ω/km |
American Wire Gauge | 26 AWG |
Connector 1 Housing Gender | Female |
Operating Temperature Range | -40 → +80 °C |
Maximum Operating Temperature | +80°C |
Conductor Material | Tin Plated Copper Litz Wires |
Minimum Bend Radius | 54 mm |
Minimum Operating Temperature | -40°C |
Standards Met | EAC |
Oil Resistant | Yes |
