คุณสมบัติ / Specifications
| คุณสมบัติ | รายละเอียด |
|---|---|
| Sensor Style | Block |
| Detection Type | Through Beam (Emitter and Receiver) |
| Detection Range | 0 → 20 m |
| Output Type | NPN-NO/NC, PNP-NO/NC, Push Pull |
| Electrical Connection | 4-Pin M8 Connector |
| Maximum DC Voltage | 30V |
| Optical Technology | Laser |
| Terminal Type | 4-Pin Connector |
| Light Source | Laser Diode |
| IP Rating | IP67, IP69, IP69K |
| Maximum Current | 100 mA |
| Response Time | 0.4 ms |
| Interface | IO-Link |
| Housing Material | PC |
| Standards Met | CE, CULus, E 87056, EMC Directive 2004/108/EC, EN 60825-1:2007, EN 60947-5-2:2007, EN 61131-9:2013, EN 62471:2008, IEC 60825-1:2007, IEC 60947-5-2:2007, IEC 61131-9:2013, UL 60947-5-2: 2014 |
| Minimum Operating Temperature | -40°C |
| Series | OBE20M |
| Maximum Operating Temperature | +60°C |
| Mounting Type | Panel Mount |
