คุณสมบัติ / Specifications
| คุณสมบัติ | รายละเอียด |
|---|---|
| Sensor Style | Block |
| Detection Type | Diffuse |
| Detection Range | Maximum of 9.5 mm |
| Output Type | NPN, PNP, Push Pull |
| Electrical Connection | 5-Pin M12 Connector |
| Maximum DC Voltage | 30V |
| Optical Technology | LED |
| Terminal Type | M12 Connector |
| Light Source | LED |
| IP Rating | IP67 |
| Maximum Current | ≤70 mA |
| Response Time | 30 μs |
| Housing Material | PC |
| Minimum Operating Temperature | -20°C |
| Maximum Operating Temperature | +60°C |
| Series | DK20 |
| Standards Met | CE, CULus |
| Mounting Type | Threaded |
