คุณสมบัติ | รายละเอียด |
|---|---|
| Coil Voltage | 12V dc |
| Contact Configuration | SPST |
| Mounting Type | PCB Mount |
| Switching Current | 10A |
| Number of Poles | 1 |
| Latching | No |
| Terminal Type | PCB Pin |
| Maximum Switching Voltage AC | 250V |
| Maximum Switching Voltage DC | 125V dc |
| Length | 20mm |
| Coil Resistance | 720Ω |
| Coil Power | 200mW |
| Height | 10mm |
| Life | 10^5 (Electrical) Operations, 5 x 10^7 (Mechanical) Operations |
| Minimum Operating Temperature | -40°C |
| Maximum Operating Temperature | +65°C |
| Isolation Coil To Contact | 4kVrms |
| Depth | 12.5mm |
| Maximum Switching Power DC | 300 W |
| Maximum Switching Power AC | 2.5 kVA |
| Application | Domestic Appliances, Office Equipment |
