คุณสมบัติ | รายละเอียด |
|---|---|
| Coil Voltage | 24V dc |
| Contact Configuration | DPST, SPST |
| Mounting Type | PCB Mount |
| Switching Current | 35A |
| Number of Poles | 3 |
| Latching | No |
| Terminal Type | PCB Pin |
| Maximum Switching Voltage AC | 277 (Form B) V, 480 (Form A) V |
| Maximum Switching Voltage DC | 110V dc |
| Length | 30mm |
| Coil Resistance | 306.4Ω |
| Coil Power | 1.88W |
| Standards Met | cUL, cULus, UL, VDE |
| Contact Material | Silver Alloy |
| Depth | 36mm |
| Life | Minimum of 100000 (Form B-Electrical) operations, Minimum of 30000 (Form A-Electrical) operations, Minimum of 5000000 (Mechanical) operations |
| Isolation Coil To Contact | 2000 (Form A) Vrms, 2000 (Form B) Vrms |
| Maximum Operating Temperature | +85°C |
| Minimum Operating Temperature | -40°C |
| Height | 40mm |
| Maximum Switching Power AC | 277 (Form B) VA, 9695 (Form A) VA |
| Application | Industrial Equipment, Inverter, Office Air Conditioner, Photovoltaic Power Generation Systems, Uninterruptible Power Supplies |
