คุณสมบัติ / Specifications
คุณสมบัติ | รายละเอียด |
---|---|
Actuator Type | Plunger |
Pole and Throw Configuration | SPDT |
Normal State Configuration | NO/NC |
IP Rating | IP67 |
Maximum Current | 10 A |
Maximum AC Voltage | 250V |
Maximum DC Voltage | 250V |
Contact Type | Snap Action |
Terminal Type | Screw |
Length | 69.4mm |
Width | 70mm |
Maximum Operating Temperature | +80°C |
Dimensions | 69.4 x 70 x 21.7 mm |
Depth | 21.7mm |
Minimum Operating Temperature | -10°C |
Mechanical Life Minimum | 10000000 cycles |
