คุณสมบัติ / Specifications
คุณสมบัติ | รายละเอียด |
---|---|
Actuator Type | Roller Lever |
Pole and Throw Configuration | SPDT |
Normal State Configuration | NO/NC |
IP Rating | IP67 |
Maximum Current | 10 A @ 250 V ac |
Housing Material | Die Cast Aluminium |
Maximum AC Voltage | 600V |
Maximum DC Voltage | 250V |
Connection Type | Snap-On |
Series | WL |
Contact Type | Snap Action |
Terminal Type | Conduit |
Length | 96.7mm |
Width | 40mm |
Mounting Orientation | Side |
Dimensions | 96.7 x 40 x 42 mm |
Minimum Operating Temperature | -10°C |
Depth | 42mm |
Mechanical Life Minimum | 15000000 Operations |
Maximum Operating Temperature | +80°C |
