คุณสมบัติ / Specifications
| คุณสมบัติ | รายละเอียด |
|---|---|
| Actuator Type | Roller Lever |
| Pole and Throw Configuration | SPST |
| Normal State Configuration | NO/NC |
| IP Rating | IP67 |
| Maximum Current | 10 A |
| Maximum AC Voltage | 500V |
| Maximum DC Voltage | 250V |
| Connection Type | M20 |
| Series | WL |
| Contact Type | Snap Action |
| Terminal Type | Screw |
| Length | 40mm |
| Width | 53.2mm |
| Mounting Orientation | Back, Front |
| Standards Met | CCCS, CE Certified, CULus Listed, EN/IEC, UL |
| Minimum Operating Temperature | -10°C |
| Depth | 94.1mm |
| Dimensions | 40 x 53.2 x 94.1 mm |
| Operating Force | 13.34N |
| Mechanical Life Minimum | 15000000 Operations |
| Maximum Operating Temperature | +85°C |
