| คุณสมบัติ | Value |
|---|---|
| AC or DC Input Voltage | Ac, Dc |
| AC or DC Output Voltage | Dc |
| Input Voltage | 85 → 264 V ac, 90 → 350 V dc |
| Minimum Input Voltage | 85 V ac, 90 V dc |
| Maximum Input Voltage | 264 V ac, 350 V dc |
| Output Voltage | 24 V dc |
| Output Current | 1.3 A |
| Power Rating | 30W |
| Number of Outputs | 1 |
| Electrical Phase | 1 |
| Type | Switched Mode Power Supply |
| Dimensions | 32 x 91.2 x 90mm |
| Height | 90mm |
| Width | 32mm |
| Depth | 91.2mm |
| Input Frequency Range | 47 → 450Hz |
| Protection Features | Over Current Protection, Over Voltage Protection, Overload Protection |
| Maximum Temperature | +70°C |
| Weight | 250g |
| Efficiency | 86 % @ 230 V ac, 87 % @ 115 V ac |
| Maximum Input Current | 580 mA @ 115 V ac |
| Ripple And Noise | 190mV Pk-Pk |
| Minimum Temperature | -40°C |
| Power Signal Conversion Type | AC/DC-DC |
| Series | S8VK-S |
| MTBF | 135000h |
| Allowed Circuit Configurations | Parallel, Series |
| Load Regulation | 1.5% |
| Holdup Time | 30 ms @ 115 V ac, 140 ms @ 230 V ac |
| Input Electrical Phase | Single Phase |
| Mounting Type | DIN Rail |
