คุณสมบัติ | รายละเอียด |
---|---|
Coil Voltage | 24V dc |
Contact Configuration | DPDT |
Mounting Type | PCB Mount |
Switching Current | 10A |
Number of Poles | 2 |
Latching | No |
Terminal Type | PCB Pin |
Maximum Switching Voltage AC | 250V ac |
Maximum Switching Voltage DC | 125V dc |
Length | 21.5mm |
Coil Resistance | 650Ω |
Coil Power | 900mW |
Life | 100000000 (Mechanical) Operations, 500000 (Electrical) Operations |
Height | 28mm |
Depth | 36mm |
Series | LY2 |
Maximum Operating Temperature | +55°C |
Isolation Coil To Contact | 2kV ac |
Minimum Operating Temperature | -25°C |
Contact Material | Silver Alloy |
Maximum Switching Power DC | 240 W |
Maximum Switching Power AC | 1.1 kVA |
Application | General Purpose, Power |
