Omron K3HB-VLC 100/240VAC LED Digital Panel Multi-Function Meter for Load

รายละเอียดสินค้า / Product Details

K3HB-R Rotary Pulse Input Meter

For measuring rate, ratios, differences and passing time applications. An encoder is used to provide a pulsed input, the meter then calculate based on this to provide the operation required. A power supply is an option available to power the encoder (see options and accessories section for more information).

 - Two standard models with pulse input speed up to 50 kHz maximum

 - Colour change display to give process status

 - Programmable bar graph to show magnitude

 - PNP, NPN, and open collector input options up to 50 kHz

 - Accuracy: Functions F1, F6: ±0.006% rdg ±1 digit (for voltage pulse/open collector sensors); Functions F2 to F5: ±0.02% rdg ±1 digit (for voltage pulse/open collector sensors)

Omron K3HB Series

This new range of Process Panel Meters replaces the K3N Series. K3HB series consists of process, temperature, weighing and linear sensor indicators. These indicators with analogue inputs or pulse inputs feature a clear and easy-to-use colour-change display and all have IP66 housing. Extra functionality can be added using option boards (3 maximum).

Dimensions: 101.2 x 112 x 48 mm. Panel cut-out: 92 x 45 mm

คุณสมบัติ / Specifications

 - Properties Measured Load, Pressure, Torque, Weight

 - Display Type LED

 - Cutout Height 45mm

 - Cutout Width 92mm

 - Depth 112mm

 - Minimum Temperature -10°C

 - Maximum Temperature +55°C
