| Attribute | Value |
|---|---|
| Supply Voltage | 24 → 230 V ac, 24 → 48 V dc |
| Time Range | 0.1 s → 12 h |
| Mode of Operation | Flicker OFF, Flicker ON |
| Mounting Type | DIN Rail |
| Number of Timer Functions | Multi Function |
| Number of Contacts | 1 |
| Series | H3DS |
| Time Increment | Hours, Seconds |
| Power Supply | External |
| Current Maximum | 5 A |
| Terminal Type | Screw |
| Minimum Voltage | 5 V dc |
| Maximum Voltage | 125 V dc |
| Minimum Operating Temperature | -10°C |
| Width | 17.5mm |
| Length | 80mm |
| Switch Configuration | SPDT |
| Maximum Operating Temperature | +55°C |
| Depth | 73mm |
