คุณสมบัติ | รายละเอียด |
|---|---|
| Coil Voltage | 5V dc |
| Contact Configuration | DPDT |
| Mounting Type | Surface Mount |
| Maximum Switching Voltage AC | 125V ac |
| Maximum Switching Voltage DC | 60V dc |
| Maximum Switching Power DC | 30 W |
| Latching | Yes |
| Length | 10mm |
| Depth | 6.5mm |
| Height | 5mm |
| Dimensions | 10 x 5 x 6.5mm |
| Terminal Type | Through Hole |
| Application | Signal |
| Maximum Switching Power AC | 37.5VA |
| Minimum Operating Temperature | -40°C |
| Operating Temperature Range | -40 - +70°C |
| Coil Resistance | 237Ω |
| Contact Material | Gold Plated |
| Maximum Operating Temperature | +70°C |
