คุณสมบัติ | รายละเอียด |
|---|---|
| Coil Voltage | 24V dc |
| Contact Configuration | DPDT |
| Mounting Type | PCB Mount |
| Maximum Switching Current AC | 2 A |
| Maximum Switching Current DC | 1 A |
| Maximum Switching Voltage AC | 250V |
| Maximum Switching Voltage DC | 220V |
| Maximum Switching Power DC | 60 W |
| Series | G6A |
| Latching | No |
| Length | 20.2mm |
| Depth | 10.1mm |
| Height | 8mm |
| Dimensions | 20.2 x 8 x 10.1mm |
| Terminal Type | PCB Pin |
| Application | Signal |
| Number of Poles | 2 |
| Switching Current | 2A |
| Minimum Operating Temperature | -40°C |
| Isolation Coil To Contact | 1.5kV rms |
| Maximum Operating Temperature | +70°C |
| Features | Resistant To Electromagnetic Interference, Conforms to FCC Part Requirements, Bifurcated Contacts |
| Operating Temperature Range | -40 - +70°C |
| Life | 500000 Operations |
| Contact Material | Gold Plated |
| Coil Power | 200mW |
| Maximum Switching Power AC | 125 VA |
| Coil Resistance | 2.88 kΩ |
