คุณสมบัติ | รายละเอียด |
|---|---|
| Coil Voltage | 48V dc |
| Contact Configuration | DPDT |
| Mounting Type | PCB Mount |
| Maximum Switching Current AC | 2 A |
| Maximum Switching Current DC | 1 A |
| Maximum Switching Voltage AC | 250V |
| Maximum Switching Voltage DC | 220V |
| Maximum Switching Power DC | 60 W |
| Series | Axicom P2 |
| Latching | No |
| Length | 20.2mm |
| Depth | 10.1mm |
| Height | 8mm |
| Dimensions | 20.2 x 8 x 10.1mm |
| Terminal Type | PCB Pin |
| Number of Poles | 2 |
| Switching Current | 2A |
| Application | Power |
| Coil Power | 235mW |
| Isolation Coil To Contact | 1.5kV rms |
| Features | Resistant To Electromagnetic Interference, Conforms to FCC Part Requirements, Bifurcated Contacts |
| Contact Material | Gold Plated |
| Maximum Operating Temperature | +70°C |
| Minimum Operating Temperature | -40°C |
| Operating Temperature Range | -40 - +70°C |
| Coil Resistance | 9.75 kΩ |
| Maximum Switching Power AC | 125 VA |
