คุณสมบัติ / Specifications
| คุณสมบัติ | รายละเอียด |
|---|---|
| Series | F3SG-RE |
| Beam Resolution | 14mm |
| Component Type | Receiver, Sender |
| Safety Type | 2 |
| PL EN ISO 13849-1 | c |
| Number of Beams | 71 |
| Protective Height | 720mm |
| Minimum Scanning Distance | 0.3m |
| Maximum Scanning Distance | 10m |
| Maximum Response Time | 145 (OFF to ON Not Synchronized) ms, 45 (OFF to ON Synchronized) ms, 9 (ON to OFF) ms |
| Length | 35mm |
| Height | 720mm |
| Supply Voltage | 24 V dc |
| Terminal Type | 4-Pin M12 Connector |
| Application | Arm, Finger, Hand |
| Dimensions | 35 x 35 x 720 mm |
| Features | Downsized, Easy Adjustment after Mounting, Ensuring Safe Restart, No Torque Control Required, Protected with Protection Cover, Quick Troubleshooting, Reducing Stops Due to Mutual Interference, Reliable Even in Harsh Environment, Robust & Compact Design, Slim Housing, Smart Muting Actuator, Used in Global & Harsh Environment |
| Width | 35mm |
