คุณสมบัติ / Specifications
| คุณสมบัติ | รายละเอียด |
|---|---|
| Input Voltage | 88 → 264 V ac, 124 → 370 V dc |
| Minimum Input Voltage | 88V ac |
| Output Voltage | 24 V dc |
| Maximum Input Voltage | 264V ac |
| Minimum Output Voltage | 24V dc |
| Maximum Output Voltage | 28V dc |
| Output Current | 5 A |
| Power Rating | 120W |
| Number of Outputs | 1 |
| Electrical Phase | 1 |
| Type | Switch Mode |
| Dimensions | 125.2 x 40 x 113.5mm |
| Height | 125.2mm |
| Width | 40mm |
| Ripple And Noise | 100mV Pk-Pk |
| Input Frequency Range | 47 → 63Hz |
| Application | Electromechanical, Factory Automation, Marine Related Installation, Semiconductor Fabrication Equipment |
| Load Regulation | ±1% |
| Standards Met | RoHS Compliant, TUV EN 60950-1, UL 508 |
| Holdup Time | 20 ms @ 115 V ac, 20 ms @ 230 V ac |
| Series | SDR |
| MTBF | 289.9kh |
| Special Features | Overvoltage and Short Circuit Protection |
| Maximum Input Current | 1.4 A @ 115 V ac, 700 mA @ 230 V ac |
| Depth | 113.5mm |
| Minimum Temperature | -25°C |
| Output Voltage Adjustment Range | 24 → 28V |
| Mounting Type | DIN Rail |
| Power Signal Conversion Type | AC-DC |
| Maximum Temperature | +70°C |
| Weight | 670g |
| Protection Features | Over Temperature Protection, Over Voltage Protection, Overload Protection, Short Circuit Protection |
| Line Regulation | ±0.5% |
