คุณสมบัติ / Specifications
| คุณสมบัติ | Value |
|---|---|
| Output Voltage | 12V dc |
| Input Voltage Range | 72 → 144 V dc |
| Input Voltage Nominal | 96 V dc |
| Isolation Voltage | 2kV ac |
| Power Rating | 500W |
| Output Current | 40A |
| Mounting Type | Chassis Mount |
| Number of Outputs | 1 |
| Efficiency | 87% |
| Minimum Temperature | -20°C |
| Maximum Temperature | +60°C |
| Load Regulation | ±0.5% |
| Line Regulation | ±0.5% |
| Regulator Type | Switch Mode |
| Standards Met | EN 55022 (CISPR22) Class B, EN 61000-4-2, ENV 50204, Heavy Industry Level Criteria A, 3, 4, 5, 6, 8 |
| Ripple And Noise | 150mV |
| Width | 115mm |
| Protection Features | Over Temperature Protection, Over Voltage Protection, Overload Protection, Short Circuit Protection |
| Weight | 1.2kg |
| Length | 215mm |
| Special Features | 3-Years Warranty |
| MTBF | 196.3kh |
| Current Limiting Method | Constant Current Limiting |
| Depth | 50mm |
| Power Signal Conversion Type | DC-DC |
| Output Voltage Adjustment Range | 11 → 15V |
