คุณสมบัติ / Specifications
| คุณสมบัติ | Value |
|---|---|
| Output Voltage | 12V dc |
| Input Voltage Range | 19 → 36 V dc |
| Input Voltage Nominal | 24 V dc |
| Isolation Voltage | 1.5kV ac |
| Power Rating | 25W |
| Output Current | 2.1A |
| Mounting Type | Chassis Mount |
| Number of Outputs | 1 |
| Efficiency | 75% |
| Minimum Temperature | -10°C |
| Maximum Temperature | +60°C |
| Load Regulation | ±0.3% |
| Line Regulation | ±0.3% |
| Current Limiting Method | Hiccup Current Limiting |
| Special Features | 2 Year Warranty |
| MTBF | 365.9kh |
| Output Voltage Adjustment Range | 11 → 16V |
| Power Signal Conversion Type | DC-DC |
| Length | 99mm |
| Protection Features | Over Voltage Protection, Overload Protection, Short Circuit Protection |
| Width | 97mm |
| Ripple And Noise | 120mV |
| Standards Met | EN 55022 (CISPR22) Class B, EN 61000-4-2, ENV 50204, Heavy Industry Level Criteria A, 3, 4, 5, 6, 8 |
| Regulator Type | Switch Mode |
| Depth | 36mm |
| Weight | 380g |
