คุณสมบัติ / Specifications
คุณสมบัติ | Value |
---|---|
Output Voltage | 12V dc |
Input Voltage Range | 19 → 36 V dc |
Input Voltage Nominal | 36 V dc |
Isolation Voltage | 1.5kV ac |
Power Rating | 150W |
Output Current | 12.5A |
Mounting Type | Chassis Mount |
Number of Outputs | 1 |
Efficiency | 75% |
Minimum Temperature | -10°C |
Maximum Temperature | +60°C |
Load Regulation | ±0.5% |
Line Regulation | ±0.5% |
Depth | 50mm |
Power Signal Conversion Type | DC-DC |
Length | 199mm |
Regulator Type | Switch Mode |
Standards Met | EN 55022 (CISPR22) Class B, EN 61000-4-2, ENV 50204, Heavy Industry Level Criteria A, 3, 4, 5, 6, 8 |
Holdup Time | 24ms |
Output Voltage Adjustment Range | 11 → 16V |
Current Limiting Method | Hiccup Current Limiting |
Special Features | 2 Year Warranty |
Weight | 860g |
Protection Features | Over Voltage Protection, Overload Protection |
Width | 110mm |
Ripple And Noise | 120mV |
MTBF | 296.2kh |
