คุณสมบัติ / Specifications
| คุณสมบัติ | รายละเอียด |
|---|---|
| Load Regulation | ±0.5% |
| Input Voltage | 90 → 264 V ac, 127 → 370 V dc |
| Output Voltage | 48 V dc |
| Output Current | 42A |
| Power Rating | 2016W |
| Number of Outputs | 1 |
| Mounting Type | Encapsulated |
| Efficiency | 86% |
| MTBF | 600100h |
| Line Regulation | ±0.5% |
| Ripple And Noise | 300mV Pk-Pk |
| Weight | 1.3kg |
| Minimum Temperature | -40°C |
| Output Voltage Adjustment Range | 42 → 56V |
| Length | 295mm |
| Maximum Temperature | +70°C |
| Protection Features | Over Temperature Protection, Over Voltage Protection, Overload Protection, Short Circuit Protection |
| Width | 127mm |
| Input Frequency Range | 47 → 63Hz |
| Special Features | Built in Passive PFC Function, High Power Density, Hot Swappable, Low Profile, Output Voltage Trimming (TRM), Universal AC Input |
| Standards Met | TUV EN 60950-1, UL 60950-1 |
| Holdup Time | 20 ms @ 230 V ac |
| Depth | 41mm |
| Maximum Input Current | 16A |
