คุณสมบัติ / Specifications
| คุณสมบัติ | รายละเอียด |
|---|---|
| Input Voltage | 90 → 264 V ac, 127 → 370 V dc |
| Minimum Input Voltage | 90V ac |
| Maximum Input Voltage | 264V ac |
| Output Voltage | 48 V dc |
| Minimum Output Voltage | 48V dc |
| Maximum Output Voltage | 55V dc |
| Output Current | 10 A |
| Power Rating | 480W |
| Number of Outputs | 1 |
| Electrical Phase | 1 |
| Type | Switch Mode |
| Height | 125.2mm |
| Dimensions | 125.2 x 85.5 x 128.5mm |
| Width | 85.5mm |
| Power Signal Conversion Type | AC/DC-DC |
| Line Regulation | ±0.5% |
| Input Frequency Range | 47 → 63Hz |
| Ripple And Noise | 150mV Pk-Pk |
| Maximum Temperature | +70°C |
| Weight | 1.5kg |
| Depth | 128.5mm |
| Maximum Input Current | 2.4 A @ 230 V ac, 4.8 A @ 115 V ac |
| Mounting Type | DIN Rail |
| Protection Features | Over Temperature Protection, Over Voltage Protection, Overload Protection, Short Circuit Protection |
| Minimum Temperature | -20°C |
| Output Voltage Adjustment Range | 48 → 55V |
| Holdup Time | 16 ms @ 115 V ac, 16 ms @ 230 V ac |
| Series | NDR |
| Standards Met | RoHS Compliant, TUV EN 60950-1, UL 508 |
| Input Electrical Phase | Single Phase |
| Load Regulation | ±1% |
| Special Features | Overvoltage and Short Circuit Protection |
| MTBF | 146.8kh |
