คุณสมบัติ / Specifications
| คุณสมบัติ | รายละเอียด |
|---|---|
| Input Voltage | 9 → 36V dc |
| Minimum Input Voltage | 9V dc |
| Maximum Input Voltage | 36V dc |
| Output Voltage | 5 V dc |
| Maximum Output Voltage | 5V dc |
| Output Current | 10.8 A |
| Power Rating | 54W |
| Number of Outputs | 1 |
| Dimensions | 52.5 x 54.5 x 90mm |
| Height | 90mm |
| Width | 52.5mm |
| Load Regulation | ±1.5 |
| Output Voltage Adjustment Range | 4.5 → 5.5V |
| Holdup Time | 5ms |
| Maximum Temperature | +85°C |
| Maximum Input Current | 3A |
| Depth | 54.5mm |
| Line Regulation | ±0.5% |
| Ripple And Noise | 60mV Pk-Pk |
| Minimum Temperature | -40°C |
| MTBF | 611kh |
| Weight | 216g |
| Series | DDR-60 |
| Mounting Type | DIN Rail Mount |
| Power Signal Conversion Type | DC-DC |
