คุณสมบัติ | รายละเอียด |
|---|---|
| Series | RKWT |
| Number of Cores | 4 |
| Cross Sectional Area | 0.34 mm² |
| Sheath Colour | Black |
| Sheath Material | Polyurethane PUR |
| Length | 15m |
| Connector 1 Orientation | Right Angle |
| Connector 1 Number of Contacts | 4 |
| Connector 1 Gender | Female |
| Connector 1 | M12 |
| Connector 2 | Unterminated |
| Coding | A |
| Shielded/Unshielded | Unshielded |
| Shielding | Unshielded |
| Current Rating | 4 A |
| Voltage Rating | 30 V |
| IP Rating | IP65, IP67, IP68, IP69K |
| Insulation Material | PP |
| Conductor Material | Copper |
| American Wire Gauge | 22 AWG |
| Minimum Operating Temperature | -40°C |
| Maximum Operating Temperature | +90°C |
| Cable Shape | Round |
| Outer Diameter | 4.7mm |
| Operating Temperature Range | -40 - +90 °C |
| Minimum Bend Radius | 5 x D |
