คุณสมบัติ | รายละเอียด |
|---|---|
| Series | RST |
| Number of Cores | 3 |
| Cross Sectional Area | 0.34 mm² |
| Sheath Material | PUR |
| Sheath Colour | Black |
| Length | 2m |
| Connector 1 Gender | Male |
| Connector 1 Number of Contacts | 3 |
| Connector 1 | M12 |
| Connector 1 Orientation | Straight |
| Connector 2 | M8 |
| Connector 2 Orientation | Straight |
| Connector 2 Gender | Female |
| Connector 2 Housing Gender | Female |
| Connector 2 Number of Contacts | 3 |
| Coding | A |
| Shielding | Unshielded |
| Shielded/Unshielded | Unshielded |
| Current Rating | 4 A |
| Voltage Rating | 60 V |
| IP Rating | IP65, IP67, IP68, IP69 |
| Maximum Operating Temperature | +90°C |
| Operating Temperature Range | -40 → +90 °C |
| Number of Strands | 3 |
| Connector 1 Housing Gender | Male |
| Outer Diameter | 4.30mm |
| Conductor Resistance | 10 mΩ |
| Insulation Material | PP |
| Fire Behaviour | Halogen Free |
| Minimum Operating Temperature | -40°C |
| Standards Met | IEC 60754-1 |
| Oil Resistant | Yes |
| Cable Shape | Multicore |
| Minimum Bend Radius | 5 mm |
| Conductor Material | Copper |
