คุณสมบัติ / Specifications
คุณสมบัติ | รายละเอียด |
---|---|
Supply Voltage | 12 → 240 V ac/dc |
Time Range | 0.1 s → 10 days |
Mode of Operation | Flash Start with OFF, Flash Start with ON, OFF Delay, ON Delay, Pulse ON Relay |
Mounting Type | DIN Rail |
Number of Timer Functions | Multi Function |
Number of Contacts | 3 |
Power Supply | External |
Contact Configuration | NO/CO |
Current Maximum | 8 A |
Terminal Type | Screw |
Length | 17.5mm |
Width | 104.7mm |
Time Delay | 25 ms |
Maximum Operating Temperature | +60°C |
Depth | 64.9mm |
Minimum Operating Temperature | -20°C |
Switch Configuration | SPDT |
