คุณสมบัติ | รายละเอียด |
|---|---|
| Maximum Load Current | 1.5 A rms/A dc, 2.5 A dc |
| Mounting Type | Surface Mount |
| Switching Type | AC/DC |
| Number of Poles | 1 |
| Contact Configuration | SPST |
| Terminal Type | PCB Pin |
| Output Device | MOSFET |
| Relay Type | OptoMOS |
| Package Style | Small - 6 Pin |
| Maximum Turn On Time | 4ms |
| Dimensions | 8.382 x 6.35 x 3.302mm |
| Height | 3.3mm |
| Depth | 6.4mm |
| Maximum Operating Temperature | +85°C |
| Capacitance | 200pF |
| Minimum Operating Temperature | -40°C |
| Standards Met | CSA, EN/IEC 60950, Certificate TUV B 09 07 49140 004, UL File E76270 |
| Special Features | Arc-Free With No Snubbing Circuits, High Reliability, Immune to Radiate FM Interface, No EMI/RFI Generation, Wave Solderable |
| Operating Temperature Range | -40 → +85°C |
| Off State Leakage Current | 1 μA |
| Length | 8.4mm |
