คุณสมบัติ | รายละเอียด |
|---|---|
| Coil Voltage | 24V dc |
| Contact Configuration | DPDT |
| Mounting Type | Plug In |
| Switching Current | 10A |
| Number of Poles | 2 |
| Latching | No |
| Terminal Type | Plug In |
| Maximum Switching Voltage AC | 250V |
| Maximum Switching Voltage DC | 30V dc |
| Length | 35.5mm |
| Coil Resistance | 430Ω |
| Coil Power | 1.5W |
| Standards Met | cULus File No. 134517 Recognized |
| Isolation Coil To Contact | 2.5kV ac |
| Minimum Operating Temperature | -40°C |
| Contact Material | Silver Alloy |
| Depth | 35.5mm |
| Maximum Operating Temperature | +55°C |
| Life | 100000 (Electrical) operations, 10000000 (Mechanical) operations |
| Height | 55.3mm |
| Maximum Switching Power DC | 300 W |
| Maximum Switching Power AC | 2.5 kVA |
| Application | Industrial |
G5LE-1A-E DC24
G7L-2A-P 200/240AC
G2R-2-SNI DC24(S)
G5PZ-1A4-E-DC24
C5-A30X/024VDC
HF115FK/24-2Z4T(610)
