คุณสมบัติ | รายละเอียด |
|---|---|
| Coil Voltage | 24V ac |
| Contact Configuration | DPDT |
| Mounting Type | Plug In |
| Switching Current | 10A |
| Number of Poles | 2 |
| Latching | No |
| Terminal Type | Plug In |
| Maximum Switching Voltage AC | 250V |
| Maximum Switching Voltage DC | 30V dc |
| Length | 35.5mm |
| Coil Resistance | 70Ω |
| Coil Power | 2.7W |
| Height | 55.3mm |
| Standards Met | cULus File No. 134517 Recognized |
| Isolation Coil To Contact | 2.5kV ac |
| Maximum Operating Temperature | +55°C |
| Minimum Operating Temperature | -40°C |
| Contact Material | Silver Alloy |
| Life | 100000 (Electrical) operations, 10000000 (Mechanical) operations |
| Depth | 35.5mm |
| Maximum Switching Power AC | 2.5 kVA |
| Maximum Switching Power DC | 300 W |
| Application | Industrial |
