คุณสมบัติ | รายละเอียด |
|---|---|
| Coil Voltage | 230V ac |
| Contact Configuration | DPDT |
| Mounting Type | DIN Rail |
| Number of Poles | 2 |
| Load Current Rating | 16A |
| Maximum Input Voltage | 250V ac |
| Terminal Type | Screw |
| Switching Voltage | 230 V ac → 250V ac |
| Depth | 15.8mm |
| Height | 76mm |
| Length | 76mm |
| Series | RMTFL |
| Contact Material | Silver Alloy |
| Input Current | 8A |
| Minimum Operating Temperature | -40°C |
| Relay Switching Classification | Interface Relay Module |
| Control Resistance | 100mΩ |
| Standards Met | CE, cURus, DVE |
| Special Features | Change Over Contacts, Supplied Completed, Relay, Socket, Ejector, Clip and Identification Label, 1 Part Number for Simple Ordering, AC & DC Coils, Built in Supply Status LED, 35mm DIN Rail Mounting, Built in Test Button & Flag Indicator |
| Maximum Operating Temperature | +70°C |
| Turn On Time | 15ms |
| Dimensions | 76 x 15.8 x 76mm |
| Turn Off Time | 8ms |
| Operating Temperature Range | -40 → +70°C |
