คุณสมบัติ / Specifications
คุณสมบัติ | รายละเอียด |
---|---|
Actuator Type | Side Rotary Roller Lever |
Pole and Throw Configuration | SPDT 1NO/1NC |
Normal State Configuration | NO/NC |
IP Rating | IP66 |
Maximum Current | 10 A |
Housing Material | Plastic, Polyester |
Maximum AC Voltage | 300V |
Maximum DC Voltage | 300V |
Connection Type | Internal Screw Terminal Contact Block |
Series | GLD |
Contact Type | Snap Action |
Terminal Type | 1/2-14NPT Conduit |
Length | 68.5mm |
Width | 30.5mm |
Mechanical Life Minimum | 10000000 Cycles |
Mounting Orientation | EN50047 |
Standards Met | CCC, CE, CSA, UL |
Minimum Operating Temperature | -40°C |
Depth | 26.35mm |
Dimensions | 30.5 x 30 x 55 mm |
Maximum Operating Temperature | +85°C |
