คุณสมบัติ / Specifications
คุณสมบัติ | รายละเอียด |
---|---|
Actuator Type | Plunger |
Pole and Throw Configuration | SPDT |
Normal State Configuration | NO/NC |
IP Rating | IP67 |
Maximum Current | 6 A |
Housing Material | Die Cast Zinc |
Maximum AC Voltage | 600V |
Maximum DC Voltage | 250V |
Series | GLA |
Contact Type | Snap Action |
Terminal Type | PG13.5 Connector |
Length | 145.8mm |
Width | 42mm |
Mechanical Life Minimum | 15000000 cycles |
Depth | 42mm |
Maximum Operating Temperature | +85°C |
Dimensions | 145.8 x 42 x 42 mm |
Minimum Operating Temperature | -25°C |
