คุณสมบัติ | รายละเอียด |
|---|---|
| Series | Circular Connectors M8 |
| Cross Sectional Area | 0.34 mm² |
| Number of Cores | 4 |
| Sheath Colour | Green |
| Length | 5m |
| Sheath Material | PUR |
| Connector 1 Orientation | Straight |
| Connector 1 Number of Contacts | 4 |
| Connector 1 | M8 |
| Connector 1 Gender | Male |
| Connector 2 | M8 |
| Connector 2 Housing Gender | Male |
| Connector 2 Gender | Male |
| Connector 2 Number of Contacts | 4 |
| Connector 2 Orientation | Straight |
| Coding | D |
| Shielded/Unshielded | Shielded |
| IP Rating | IP67 |
| Insulation Material | PUR |
| Conductor Material | Copper |
| Size of Strands | 22 AWG |
| Minimum Operating Temperature | -30°C |
| American Wire Gauge | 22 AWG |
| Cable Shape | Round |
| Maximum Operating Temperature | +80°C |
| Outer Diameter | 10.1mm |
| Core Strands | 7 |
| Number of Strands | 7 |
| Operating Temperature Range | -30 → +80 °C |
| Connector 1 Housing Gender | Male |
