Attribute | Value |
---|---|
Supply Voltage | 24 V ac/dc |
Time Range | 0.05 → 100 s, 3 → 100 min, 5 → 100 h |
Mode of Operation | Interval, ON Delay, Pulse Delay, Symmetrical Flash |
Mounting Type | Plug In |
Number of Timer Functions | Multi Function |
Number of Contacts | 4 |
Series | 85 Series |
Time Increment | Hours, Minutes, Seconds |
Power Supply | External |
Contact Configuration | 4NO/4NC |
Current Maximum | 20 A |
Terminal Type | 14-Pin Connector |
Maximum Voltage | 250 V ac |
Contact Material | Silver Nickel |
Maximum Operating Temperature | +60°C |
Switch Configuration | 4PDT |
Length | 59.5mm |
Width | 20.6mm |
Minimum Operating Temperature | -20°C |
CAD Drawing | 3D CAD Model |
Time Delay | <=20 ms |
Depth | 27.7mm |
