คุณสมบัติ | รายละเอียด |
|---|---|
| Maximum Load Current | 5 A |
| Mounting Type | PCB Mount |
| Maximum Load Voltage | 24 V dc |
| Minimum Load Voltage | 1.5 V dc |
| Maximum Control Voltage | 17 V dc |
| Minimum Control Voltage | 8 V dc |
| Switching Type | DC |
| Control Voltage Range | 8 → 17 V dc |
| Minimum Load Current | 1 mA |
| Terminal Type | Through Hole |
| Contact Configuration | SPST |
| Maximum Turn On Time | 0.05 ms |
| Load Voltage Range | 1.5 → 24V dc |
| Series | 41 |
| Dimensions | 29 x 12.7 x 15.7mm |
| Maximum Operating Temperature | +60°C |
| Minimum Operating Temperature | -20°C |
| Depth | 12.7mm |
| Operating Temperature Range | -20 → +60°C |
| Length | 29mm |
| Height | 15.7mm |
| Off State Leakage Current | 0.01 mA |
