คุณสมบัติ | รายละเอียด |
|---|---|
| Coil Voltage | 5V dc |
| Contact Configuration | SPDT |
| Mounting Type | PCB Mount |
| Switching Current | 6A |
| Number of Poles | 1 |
| Latching | No |
| Terminal Type | Through Hole |
| Maximum Switching Voltage AC | 400V ac |
| Length | 28mm |
| Coil Resistance | 130 Ω |
| Coil Power | 170mW |
| Height | 15mm |
| Life | 10000000 (DC Mechanical) cycles, 60000 (Electrical) cycles |
| Series | 34 Series |
| Contact Material | Silver Alloy |
| Depth | 5mm |
| Maximum Operating Temperature | +85°C |
| Minimum Operating Temperature | -40°C |
| Isolation Coil To Contact | 6kV |
| Maximum Switching Power AC | 1.5 kVA |
